Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: SC POWER
  • Model Number: KVP-12200-TDL
  • Output Power: 101 - 200W
  • Output Type: Single
  • Input Voltage: 100-130 VAC
  • Output Voltage: 12V
  • Output Frequency: 47-63HZ
  • Output Current: 16.67A
  • Product Name: SC dimmable LED driver
  • Output: 12V 200W PWM output
  • Dimming way: Triac/ Phase-cut
  • Certification: ETL, cETL, FCC, RoHS
  • Waterproof level: IP66
  • Loading: 5-100%
  • Dimming range: 0-100%
  • Size: 256*78*47 mm
  • N.W: 1.5 Kg
  • Warranty: 3 Years

Packaging & Delivery

Packaging Details 440*295*145 mm, 8pcs/ CTNS

SC LED driver ETL listed 200w waterproof electronic LED driver, triac dimmable led lighting driver 100-130V AC input

Triac/ Phase-cut constant voltage dimmable LED driver, with junction box.



Features for KVP-12200-TDL triac dimmable LED driver

  • Output constant voltage
  • Universal AC input: 100-130VAC
  • Power Factor: up to 0.65
  • High efficiency: up to 84%
  • Protection:short circuit/over loading/over current/ Over temperature
  • Full protection aluminum housing
  • Easy installation
  • Cooling by free air convection
  • Compatible with Forward phase,Magnetic low voltage,Triac Dimmers
  • Strong compatibility, flicker-free dimming
  • Suitable for LED lighting and moving sign applications and others
  • Compliance to worldwide safety regulations for lighting

Specification for KVP-48200-TDL triac dimmable LED driver

Model

KVP-12200-TDL

KVP-24200-TDL

KVP-36200-TDL

KVP-48200-TDL

Certificates

ETL,CETL,FCC pending

ETL,CETL,FCC pending

ETL,CETL,FCC pending

ETL,FCC pending

output

DC Voltage

12V

24V

36V

48V

Voltage Tolerance

±0.5V

Rated current

16.67A

8.3A

5.56A

4.17A

Rated power

200W

input

Voltage Range

 100~130VAC

Frequency Range

50~60HZ

Power Factor (Typ.)

PF≥0.65

Efficiency(Typ.)

83%

84%

84%

84%

AC Current(Typ.)

3.37A

3.33A

3.33A

3.33A

Leakage current

<0.70mA/110VAC

Protection

Short Circuit

Hiccup mode, recovers automatically after fault condition is removed

Over Current

1.4*I out

Over Loading

≤120%

Over temperature

100℃±10℃ (The output voltage will turn off when the temperature is higher then100℃±10℃, after the temperature drop off ,it will recovery) automatic

Environment

Working TEMP.

-40~+60

Working Humidity

20~90%RH, non-condensing

Storage TEMP. Humidity

-40~+80,10~95%RH

TEMP .coefficient

±0.03%/(0~50)

Vibration

10~500Hz,2G 10min./1 cycle,period for 60min. each along X,Y,Z axes



Safety& EMC

Safety standards

UL1012

Withstand voltage

I/P-O/P:1500KVAC

Isolation resistance

I/P-O/P:100MΩ/500VDC/25/70%RH

EMC EMISSION

FCC Part 15 B

others

Net. Weight

1.38Kg

Size

227*78*48mm(L*W*H)

packing

305*260*210  10PCS/CTN

Notes

1. All parameters if NOT specially mentioned are measured at 110VAC input , rated load and 25℃of ambient temperature.

2. To extend the driver's using life ,please reduce the loading at lower input voltage.

3.Loading should be 5-100%.



Pictures for KVP-48200-TDL triac dimmable LED driver

Trading terms

MOQ: 1 pcs

Payment:

Delivery: 3-7 working days according to the order

Shipping term: FedEx, DHL, UPS, TNT...

Price: Get quote
